Toyota Corolla Cross: Precaution

PRECAUTION

HANDLING PRECAUTIONS FOR SRS AIRBAG SYSTEM

CAUTION:

This vehicle is equipped with a Supplemental Restraint System (SRS). Failure to carry out service operations in the correct sequence could cause the SRS to unexpectedly deploy during servicing. This may cause a serious accident.

Before servicing (including inspection, replacement, removal and installation of parts), be sure to read the precautionary notices for Supplemental Restraint System.

Click here
